Description
x🛠 Technical Specifications
Model Information
| Parameter | Specification |
|---|---|
| 🔢 Part Number | 1785-LT |
| 🏢 Brand | Allen-Bradley |
| 🏭 Manufacturer | Rockwell Automation |
| ⚙️ Series | PLC5 Classic Series |
| 🧩 Processor Type | Processor module (1785 series) |
| 💾 Embedded RAM | 6K Words, expandable up to 14K Words |
| 🔢 Max I/O Capacity | 3072 I/O points (any mix of inputs and outputs), with up to 3072 inputs and 3072 outputs |
| 🔧 I/O Expansion | Supports up to 4 local I/O racks and 3 remote I/O racks |
Performance & Communication
| Parameter | Specification |
|---|---|
| ⏱️ Program Scan Time | 2 ms per K-word for bit logic, 8 ms per K-word (typical) |
| 📊 Max Analog I/O | 512 points |
| 🔗 Built-in Communication Ports | One standalone DH+ scanner (for both local and remote I/O), RS-232/RS-422/RS-423 communication ports |
| ⚡ I/O Scan Time per Rack | 10 ms at 57.6 kbits/s, 7 ms at 115.2 kbits/s, 3 ms at 230.4 kbits/s |
| 📦 Memory Expansion Modules | 4K RAM Expansion (1785-MR), 8K RAM Expansion (1785-MS), 8K EEPROM (1785-MJ) |
Connectivity & Hardware
| Parameter | Specification |
|---|---|
| 🔋 Battery | 1770-XY |
| 🔢 Max Number of I/O Chassis | 93 (Maximum) |
| ⚙️ Supported Hardware Addressing | 2-slot, 1-slot, and ½ slot addressing |
| 🔌 Control Coprocessor Expansion Port | Yes |
| 🔗 Max Remote I/O Per Link | 32 |
| 🔒 Module Keying | Between slots 40 and 42, and between slots 54 and 56 |
| 📍 Rack Location | 1771 I/O chassis, in the left-most slot |
Ports & Communication Interface
| Parameter | Specification |
|---|---|
| 🔌 RS-232/RS-422/RS-423 Ports | 1 port |
| 📡 Local I/O Rack Type | 16 or 32-point modules |
| 📊 Max Analog I/O per Rack | 512 points |
| 🔗 Communication Interface | DH+ channel for local and remote I/O communication |
| 📈 Maximum I/O Chassis Extended Local | None (0) |
