Technical Specifications Model Number: 05701-A-0283 Output Signal: 4-20mA analog current loop Input Voltage: 24V DC (nominal) Power Consumption: ≤ 150mA Signal Accuracy: ±0.1% of full scale Temperature Range: -40°C to +85°C Ambient Humidity: 0-95% RH (non-condensing) Mounting: DIN rail or surface mounting options Response...

Technical Specifications for Model 05701-A-0511 🔷 Model Number: 05701-A-0511 🔷 Technical Specifications Rack Type: 16-Way Rack Assembly Dimensions: 19 inches (W) x 3U (H) Mounting Type: Standard 19-inch rack-mountable Module Slots: 16 slots Weight Capacity: 13.5 kg Material: Steel/aluminum construction with a powder-coated finish...

Technical Specifications for Model 05704-A-0135 🔷 Model Number: 05704-A-0135 🔷 Technical Specifications Input Voltage: 24 VDC nominal Power Consumption: Typically 2.5 watts per channel Input Types: Analog: 4-20 mA or 0-10 VDigital: TTL, relay contacts Output Types: Analog: 4-20 mA or 0-10 VRelay outputs:...

🔑 Key Features Parameter Specification 🔌 Output Points 16 points, with relay isolation 🔋 Load Voltage/Current Ratings DC24V, 2A (resistive load)AC220V, 2A (with power factor COSφ = 1) 📉 Minimum Load DC5V, 1mA 📈 Maximum Load AC250V, DC125V ⚡ Leakage Current 0.1mA at AC220V,...

Technical Specifications Parameter Details Input Channels 1 to 32 available. Voltage Rating Operates at 24 VDC. Power Supply Voltage Range 18 to 30 VDC (user-supplied field power). Current Consumption 105 mA maximum. Input Impedance 4.2 kΩ. Minimum Pulse Width 300 microseconds. Duty Cycle Requirement...

Technical Specifications for Model 900H03-0202 🔷 Model Number: 900H03-0202 🔷 Technical Specifications Output Channels: 8 Series: ControlEdge HC900 Voltage Input: 120/240 VAC Input Frequency: 50/60 Hz Current Rating per Channel: Up to 10 A Total Output Current: 80 A max across all channels Operating...

Technical Specifications Model: CC-PUIO01 (51454205-175) Input Channels: 32 Universal Input Channels Weight: 0.35kg Analog Input Types: Range: 0-20mA or 4-20mA (active) Analog Output Types: Output Range: 4-20mA (active) Power Requirements: Operating Voltage: Typically 24V DC (verify with specific application requirements) Environmental Conditions: Operating Temperature:...

Technical Specifications Parameter Value 🔢 Part Number CC-TDIL51 51307083-175 🔌 Input Type Digital 🔢 Number of Inputs Up to 16 digital inputs per module ⚡ Input Voltage 24V DC 🔋 Input Current 3 mA per input 📶 Input Frequency Compatible with various pulse rates...

Overview The FC-CPCHAS-0003 is a 19" rack-mountable chassis designed to house controllers for both redundant and non-redundant configurations, particularly for use in Safety Manager applications. Technical Specifications Power Consumption: 5V-1: 0.05 A 5V-2: 0.05 A 5V-R: 0.05 A Physical Dimensions: Height: 4 HE (177...

📋 Technical Specifications Product Overview Model: FC-PDIO01Part Number: 51454927-176Type: Safety Digital I/O Module Electrical Specifications Voltage: 24 VDC nominalChannels: 32 Channels (Configurable as Inputs/Outputs) Application Application: Industrial Safety Systems, Control Processes, High-Safety Applications Input Characteristics Voltage Range: 0–24 VDCInput Resistance: Typically 4.7 kΩInput Signal...

Technical Specifications Manufacturer: Honeywell Product Number: FC-SDI-1624 Product Type: Digital Input Module Input Voltage: 24 VDC Current Consumption: 110 mA Number of Channels: 16 Input Type: Digital Input Signal Voltage Range: 20.4 VDC to 28.8 VDC Input Signal Current: 5 mA per channel (max)...

Overview The FC-TSKUNI-1624 Sub-D to Knife Terminals FTA is a universal field termination assembly (FTA) module designed for versatile signal connections. It supports sixteen channels and provides two knife terminals per channel for easy connection and reliable signal transmission. The TSKUNI-1624 features a 37-pole...

Honeywell Technical Specification 🔍 Model Name: PDC-CPX05 General Type Number: FS-PDC-CPX05 Cable Type: Special CC 600 World Cable Construction: 4 × 2.5 mm² (4 cores of 2.5 mm² each) Cable Length: 0.8 meters Weight: 0.15kg Connectors Type: 4-pole Mate-n-lock connectors Tyco Connector: 350779-1 Tyco...

Technical Specifications for 2MLL-C42A Module 🌐🔧 Specification Details Module Name 2MLL-C42A Interface Standard - RS232C - 2 channels- RS422/485 - 2 channels Modem Connection with Remote Yes (only on RS232C devices port) Start Bit 1 Data Bits 7 or 8 Stop Bits 1 or...

📏 Technical Specifications Parameter Details Input Voltage 115/240 VAC (Auto-selecting) Frequency 50/60 Hz Output Voltage 25 VDC (regulated) Output Current 10 Amps Power Rating 550 Watts Efficiency Typically 85% (depending on load and conditions) Cooling Convection cooled (fanless design) Operating Temperature Range 0°C to...

Technical Specifications Parameter FC-SCNT01 / FC-SCNT02 Part Number FC-SCNT01 51454926-176 Compatibility Backward-compatible with FC-SCNT01 Supported Systems Honeywell Safety Manager SC (SMSC) Redundancy Supports redundant configurations Online Replacement Yes Supported Releases R200.2 and higher Operating Temperature 0°C to +60°C Storage Temperature -40°C to +85°C Dimensions...

Technical Specifications Relay Type: Triple Double Pole Changeover (DPCO) relay Relay Switching Capacity: AC: 250V, 8A (resistive load) DC: 30V, 8A (resistive load) Control Voltage: 24V DC (nominal) Power Consumption: Typically 0.5W per relay Operating Temperature: -40°C to 70°C (-40°F to 158°F) Storage Temperature:...

Technical Specifications for Model 05701-A-0327 🔷 Model Number: 05701-A-0327 🔷 Technical Specifications Model Number: 05701-A-0327 Series: 5701 Relay Type: Double SPCO (Single Pole Change Over) Weight: 1.00 lbs (0.45 kg) Relay Contact Ratings: Voltage Rating: 120 VAC / 28 VDCCurrent Rating: 10A resistive /...

Technical Specifications Parameter Specification 📦 Model SC-TEPR01 🔌 Type Non-redundant Controller Expansion End Plate, Right 🔋 Rated Input Voltage 24 VDC ± 25% 🔌 Input Voltage Range 18 to 30 VDC 📏 Dimensions Length: 190 mm, Width: 39 mm, Height: 16 mm ⚖️ Weight...

Overview The Honeywell MC-TAMR04 is a Low Level Analog Input Multiplexer designed to efficiently manage multiple analog input signals. With the ability to handle up to 16 input channels, this device utilizes solid-state relays to ensure reliable signal processing. Technical Specifications Manufacturer: Honeywell Product...
